Tripp Lite PDU1230 power distribution unit (PDU)
Manufacturier:
TRIPP LITE
Product Number:PDU1230
Manufacturer Warranty:5-year limited warranty
See the product sheet on the manufacturer's website.4.8/5.8kW Single-Phase 200/208/240V Basic PDU, 20 Outlets (16 C13 & 4 C19), NEMA
Tripp Lite 4.8/5.8kW Single-Phase Basic PDU, 200-240V Outlets (16-C13 & 4-C19), L6-30P, 15ft Cord, 1U Rack-Mount. PDU types: Basic, Rack capacity: 1U, Mounting: Horizontal. AC outlets quantity: 20 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, Power plug: NEMA L6-30P. Cable length: 4.57 m, Certification: UL60950-1/CSA-C22.2. Nominal input voltage: 200-240 V, Maximum current: 30 A, AC input frequency: 50 - 60 Hz. Width: 444.5 mm, Depth: 132.1 mm, Dimensions (WxDxH): 445 x 132 x 45 mm
Tripp Lite Basic Power Distribution Units / PDU systems offer reliable rackmount power distribution for critical IT equipment in wiring closets, server rooms and equipment racks. Supplies continuous power from any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.
- 5.8kW 30A 208/240V single phase Basic Power Distribution Unit / PDU
- 1U horizontal 19 inch rackmount form factor installs in one rack space
- NEMA L6-30P 30A 208/240v input plug with 15 ft. / 4.5m line cord
- 20 outlets (4 C19, 4 C13 front / 12 C13 rear)
- Adjustable mounting brackets enable installation in 2 or 4 post racks, plus additional support for wallmount and under-counter mounting
- Mounting ears are reversible for front or rear facing rackmount installation
- Back-panel grounding lug
Tripp Lite Basic Power Distribution Units / PDU systems offer reliable rackmount power distribution for critical IT equipment in wiring closets, server rooms and equipment racks. Supplies continuous power from any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.
- 5.8kW 30A 208/240V single phase Basic Power Distribution Unit / PDU
- 1U horizontal 19 inch rackmount form factor installs in one rack space
- NEMA L6-30P 30A 208/240v input plug with 15 ft. / 4.5m line cord
- 20 outlets (4 C19, 4 C13 front / 12 C13 rear)
- Adjustable mounting brackets enable installation in 2 or 4 post racks, plus additional support for wallmount and under-counter mounting
- Mounting ears are reversible for front or rear facing rackmount installation
- Back-panel grounding lug
